T-Clamp (2 Part) TJ 210 hot-dip galvanised

SKU

2101855G

This 2-part T-clamp is hot-dip galvanized and is coming without bolts and nuts. In the dimensions in the illustration, A is the size for the continuous pipe, size B is for the right angle pipe. The T-clamp is available for several pipe diameters.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Grouped product items
Item #	Base Material	Diameter A	Diameter B	Finish	VPE

2101844	Press Metal	½" (21,3 mm)	½" (21,3 mm)	Hot-dip Galvanized	1
2101855	Press Metal	¾" (26,9 mm)	¾" (26,9 mm)	Hot-dip Galvanized	50
2101865	Press Metal	1" (33,7 mm)	¾" (26,9 mm)	Hot-dip Galvanized	50
2101866	Press Metal	1" (33,7 mm)	1" (33,7 mm)	Hot-dip Galvanized	50
2101876	Press Metal	1¼" (42,4 mm)	1" (33,7 mm)	Hot-dip Galvanized	50
2101886	Press Metal	1½" (48,3 mm)	1" (33,7 mm)	Hot-dip Galvanized	25
2101896	Press Metal	2" (60,3 mm)	1" (33,7 mm)	Hot-dip Galvanized	25
2101908	Press Metal	2½" (76,1 mm)	1½" (48,3 mm)	Hot-dip Galvanized	20
2101977	Press Metal	1¼" (42,4 mm)	1¼" (42,4 mm)	Hot-dip Galvanized	25
2101987	Press Metal	1½" (48,3 mm)	1¼" (42,4 mm)	Hot-dip Galvanized	25
2101988	Press Metal	1½" (48,3 mm)	1½" (48,3 mm)	Hot-dip Galvanized	25
2101989	Press Metal	1½" (48,3 mm)	2" (60,3 mm)	Hot-dip Galvanized	20
2101997	Press Metal	2" (60,3 mm)	1¼" (42,4 mm)	Hot-dip Galvanized	25
2101998	Press Metal	2" (60,3 mm)	1½" (48,3 mm)	Hot-dip Galvanized	25
2101999	Press Metal	2" (60,3 mm)	2" (60,3 mm)	Hot-dip Galvanized	20
2101909	Press Metal	2½" (76,1 mm)	2" (60,3 mm)	Hot-dip Galvanized	20
