Modular barbed wire brackets for round & box section posts
Build every common topping from one patented modular system. With just five components you assemble
15 configurations: straight (vertical 0°/90°), 45° or 60° single arms, and
double Y-arms. The interchangeable post caps make the brackets fit ø60 round,
60×60 and 60×40 posts. Bolt it together on site—no welding, fewer SKUs,
faster installs and a consistent, professional finish.
Why installers choose this system
Modular & field-configurable: five parts cover straight, angled and double Y layouts; swap parts without removing the post.
Universal fit: one platform for ø60 round, 60×60 and 60×40 posts via interchangeable post caps.
Stronger for longer: aluminium construction with durable RAL 6009/7016/9005 finish; sloped cap sheds water to protect the coating.
Low logistics footprint: compact packing, fewer transports; damaged parts can be replaced individually.
Fast installation: supplied with bolts and nuts; accurate factory geometry for repeatable alignment.
Compatibility & configurations
Posts: ø60 round, 60×60 and 60×40 box section (select matching post cap).
Forms: straight (vertical), angled 45° and 60°, double Y-arm variants.
Use-cases: perimeter security for industry, logistics hubs, utilities, airports and agricultural fencing.
Materials & finish
Material: high-grade aluminium, light in weight and corrosion-resistant.
Finish: RAL 6009 pine green, RAL 7011 iron grey, RAL 9005 jet black (other colours on request).
Post caps: sloped design for drainage; interchangeable between post types (detailed on separate cap pages).
